It is mainly used for trimming
1.Pegasus technology assembly head
2. With needle and thread cooling device, avoid broken needle,broken thread,jumper
3.Use imported motor to accurately control the sewing speed
4.Automatic lifting of pneumatic control foot, smooth operation,low noise
5.Can sew the buckle cloth at the same time.
| Technical Specifications | |
|---|---|
| Model | ZL-FG-5B |
| Sewing Speed | 2,800–3,500 stitches/min |
| Max Mattress Thickness | Up to 450 mm |
| Stitch Type | Straight line with turning support |
| Stitch Step Adjustment | Yes |
| Flip Function | One-key automatic flipping |
| Supported Mattress Types | Spring, latex, memory foam, hybrid |
| Compatible Fabrics | Woven, knitted, quilted, foam-covered |
| Production Capacity | 20–40 mattresses/hour |
| Machine Features | |
|---|---|
| Operation Type | Semi-automatic |
| Control Interface | Simple control panel |
| Construction | Steel frame with anti-rust coating |
| Expected Lifespan | 10+ years |
| Power Supply | Customizable (based on country) |
| After-sales Service | |
|---|---|
| Warranty | 12 months |
| Service Included | Installation, training, commissioning |
| Spare Parts | Available with fast delivery |
| Technical Support | Response within 24–48 hours |
Place the mattress onto the working table manually or via auxiliary transport equipment. Ensure the mattress is aligned correctly to prepare for edge sewing. Accuracy in placement ensures a straight and tight seam.
Configure machine settings through the control panel. Operators can set stitch length, speed, sewing direction, and mattress size parameters. Simple operation allows even new workers to get started quickly.
Start sewing along the edge of the mattress. The sewing head runs smoothly along the mattress perimeter. The machine ensures stable sewing performance for all standard mattress thicknesses up to 450mm.
Use one-button control to automatically flip the mattress. This function allows efficient stitching of all four sides with minimal manual effort, significantly reducing labor intensity.
ZL-FG-5B is compatible with a wide range of mattress types, including:
Spring mattresses
Memory foam mattresses
Latex mattresses
Hybrid (multi-layered) mattresses
It supports sewing through quilted, knitted, and foam-wrapped fabrics.
This machine can sew mattresses up to 450mm (45cm) thick, making it ideal for both standard and thick luxury mattresses.
Yes, the machine is designed for semi-automatic operation.
It features a simple control panel
Supports one-key mattress flipping
Requires minimal training – even beginners can operate after 1–2 hours of instruction
Yes.
ZL-FG-5B allows you to adjust the stitch step from 2mm to 5.5mm, depending on material thickness and aesthetic preference.
Sewing speed: 2,800–3,500 stitches/minute
Production output: 20–40 mattresses/hour, depending on mattress size and operator skill level.
Yes.
The machine features one-key auto flipping and corner turning, helping operators complete all four sides with minimal manual repositioning.
Yes, the ZL-FG-5B can be integrated into your existing semi-automatic or automatic production line, including conveyors, packing stations, and quality check tables.
The standard rated power is:
0.75kW
220V / 50–60Hz
We can customize voltage/frequency based on your country’s standard.
The body is made of high-strength steel with anti-rust coating
Internal components use precision mechanical parts
Designed for 10+ years of service life with proper maintenance
Tell us what you need — we’ll handle the rest.
